Extended Range
Explore further and go longer with increased capacity and greater discharge potential compared to lead-acid batteries. Utilize more capacity and charge faster with Grade A lithium.
-
Zero Maintenance
No water filling, no corrosive acids damaging your cart, and the confidence of safe long-term storage. Move to lithium and upgrade to worry-free and hassle-free operation!
-
Long Lifespan
More cycles, more performance-filled years, backed by a 10-year warranty. Our industry-best service team is here for you every mile along the way.
-
Safe and Reliable
The safest Lithium LiFePO4 chemistry, paired with advanced Battery Management technology, ensures safe operation during charging, use, and storage.
SpecificationsÂ
| BATTERIES (GEN3) | 38.4V 105Ah | 51.2V 60Ah | 51.2V 105Ah Thru-Hole |
51.2V 105Ah Skinny |
51.2V 160Ah | 70.4V 105Ah |
|---|---|---|---|---|---|---|
| Energy Capacity | 4.0 kWh | 3.0 kWh | 5.3 kWh | 5.3 kWh | 8.1 kWh | 7.3 kWh |
| Nominal Voltage | 38.4V | 51.2V | 51.2V | 51.2V | 51.2V | 70.4V |
| Nominal Ah | 105Ah | 60Ah | 105Ah | 105Ah | 160Ah | 105Ah |
| Max Discharge 5 Seconds | 600A | 500A | 600A | 600A | 600A | 600A |
| Max Discharge 10 Sec | 550A | 450A | 550A | 550A | 550A | 550A |
| Max Cont. Discharge | 250A | 200A | 250A | 250A | 250A | 250A |
| Cell Count | 12 | 16 | 16 | 16 | 32 | 22 |
| Cell Type | Prismatic | Prismatic | Prismatic | Prismatic | Prismatic | Prismatic |
| Cell Configuration | 1P12S | 1P16S | 1P16S | 1P16S | 2P16S | 1P22S |
| Cell Chemistry | Lithium Iron Phosphate | Lithium Iron Phosphate | Lithium Iron Phosphate | Lithium Iron Phosphate | Lithium Iron Phosphate | Lithium Iron Phosphate |
| Weight | 78 lbs (35.38Kg) | 78 lbs (35.38Kg) | 98 lbs (44.45Kg) | 113 lbs (51.25Kg) | 165 lbs (74.84Kg) | 146 lbs (66.22Kg) |
| Dimension LxWxH | 13.37" x 10.18" x 10.75" | 13.37" x 10.18" x 11.47" | 13.14" x 12.24" x 10.15" | 22" x 9.75" x 10.43" | 22" x 12.125" x 10.625" | 22" x 12.125" x 10.625" |
| Charging Temp Range | 32F+ | 32F+ | 32F+ | 32F+ | 32F+ | 32F+ |
| Discharge Temp Range | -4F to 140F | -4F to 140F | -4F to 140F | -4F to 140F | -4F to 140F | -4F to 140F |
| Shell Type | Powder Coated Steel | Powder Coated Steel | Powder Coated Steel | Powder Coated Steel | Powder Coated Steel | Powder Coated Steel |
| IP Rating | IP67 | IP67 | IP67 | IP67 | IP67 | IP67 |
Communication
Safety
Explore Features
Eco Battery offers complete installation solutions for your specific cart.
Power Save Mode
Eco Battery pioneered Power Save technology in the golf cart space, providing built-in protection for your battery during storage. Power Save Mode features automatic and adjustable power-off timers, offering both convenience and protection for your battery.
OEM Specific Install Kits
Installation is made easy with complete, cart manufacturer- and model-specific kits, featuring exclusive mounts, patented charge ports, and other accessories to provide a full, OEM-finished look for your new battery install.
Multiple Safeguards
We take safety seriously and ensure multiple levels of protection for a worry-free lithium experience. The proprietary Eco Battery Management System (BMS) has several built-in safeguards to monitor battery activity during charging, use, and in varying temperatures.
Robust Construction
In a cart that's always on the move, Eco Battery provides a case you can rely on. Housed in a powder-coated steel case, rated for IP67 water and weather resistance, with premium internal connections, this battery is ready for any adventure.
The Trusted Choice
Trusted by top OEMs and dealers worldwide, Eco Battery powers more cart brands than any other lithium battery. Our reputation for incredible customer support, along with a U.S.-based headquarters and team, provides a foundation you can trust for the life of your battery.
